| Brand Name : | XUANCAI |
| Model Number : | XC-36*36/28 |
| Certification : | CE ROHS LM-80 |
| Price : | $3.1-$5.9/PCS |
| Payment Terms : | T/T, Western Union, Paypal , Alibaba trade assurance |
| Supply Ability : | 10000M / Month |
| Delivery Time : | 3-5 days |
LED COB RGBW chip 36*36/28 25w for Diving light special lights, power color can be customized
Product Description
Mechanical Dimensions: 36.0x36.0x1.7(mm)
CRI(Ra):Min.90
◆RoHS compliant
◆Package Structure:Aluminium Base Chip on Board
◆Nominal CCT:4,000K
◆Better die arrangement for optics
◆Wide range of luminous fluxand high efficacy
Chromaticity Range: 3-step MacAdam Ellipse
Product Specification
| Product Name | XC-36*36/28 RGBW |
| Power | 25w |
| Current | 300mA+ 300mA+ 300mA+600mA |
| Voltage | 19-20v+17-18v+20-21v+ 20-21v |
| CRI | 90 |
| Parameter | Symbol | Rating |
| Forward Current | IF | 1500mA |
| Reverse Current | IR | 1mA |
| Operating Temperature | TOPR | -30℃ To +75℃ |
| Storage Temperature | Tst | -30℃ To +75℃ |
| Case Temperature | Tc | 85℃ |
| Junction Temperature | TJ | 125℃ |
| Soldering Temperature | TSOL | 350℃± 10℃ For 5 Seconds |
| ESD Sensitivity | ESD | 2000V HBM |
Reliability Test
No. | Test Item | Test Condition | Test Cycle |
| 1 | Continuous Operation Test | Tc=85℃ IF=1200mA | 1000H |
| 2 | Low/High Temperature Storage Test | -40℃/30min~ +100℃/30min | 100 Cycles |
| 3 | High Temperature Storage Test | Ta=100℃ | 1000H |
| 4 | Low Temperature Storage Test | Ta=-40℃ | 1000H |
| 5 | Moisture-proof Test | Tc=60℃ ,95%RH | 1000H |
